Reproducing a novel learning method for spiking NNs. Made by Anil Ozdemir using Weights & Biases

This report was originally published on OpenReview as part of the ML Reproducibility Challenge 2020.

*These two authors contributed equally.

In this report, we reproduce the results of a novel learning method for Spiking Neural Networks (SNN) proposed by Zhang and Li (2020) [23]. The proposed learning method utilises biologically more plausible neuron interactions than existing SNN algorithms.
The original paper claims that the method can produce higher performance than other state-of-the-art SNN learning algorithms on datasets such as MNIST and CIFAR-10, whilst utilising fewer timesteps.

For the reproduction of the experiments in the paper [23], we used the author's original source code with minimal additions; logging facilities and plotting functionality. We also performed an additional hyperparameter search experiment for the MNIST dataset. The experiments were run on two different GPUs, an NVIDIA Tesla V100-PCIE-32GB GPU and an NVIDIA Titan RTX. The total GPU runtimes were 150h 26m and 56h 4m, respectively. Additional to the experiments performed, we inspected the theoretical equations in the original paper. We then scrutinised the source code and the specific implementations of the mathematical equations.

Due to high computational requirements, we reproduced two out of four experiments from the original paper. Overall, the results match within a reasonable margin as reported in the paper. A Bayesian hyperparameter search, through different combinations of parameters, revealed some insights about the stability of the learning system.

The original paper is well-written, with clear explanations of the models and the learning algorithm. We also thank the authors for publishing their source code online. This made the reproduction study easier and more fruitful. The source code was written in an understandable way and the authors provided clear general instructions to rerun the networks.

The computationally demanding nature of the networks yields it challenging for us to reproduce all the experiments in the paper. Particularly, SNNs require multiple timesteps that leads proportionally longer runtime. Additionally, we discovered some parameters that were hardcoded and undocumented in the source code without explanations. We could not find their particular contexts in the original paper.

We contacted the authors on several occasions to ask questions about the paper and the undocumented parameters in the source code. They kindly clarified all our questions. We also provided some feedback regarding theoretical equations and code implementation.

Spiking Neural Network (SNN) models are based on biological networks which utilise spikes as a method of information transmission. Spiking is highly energy efficient, meaning these networks provide attractive computational solutions [5]. Several neuromorphic chip hardware have been developed to run spiking networks [1] [3], however, neural network algorithms that fully utilise their capabilities have yet to be realised. Deep neural networks have received increasing interest over recent years, inspiring the development of efficient deep spiking algorithms (Deep-SNNs) that can be run over multiple layers [17]. Deep-SNNs vary in both spatial and temporal aspects, leading to complicated network dynamics. The utilisation of spiking codes for machine learning tasks is therefore nontrivial. This is specifically due to the challenges of employing backpropagation---the typical basis for calculating weight updates. Previous spiking network algorithms have solved the problem of non-differential discrete spike events via surrogate gradients or approximation using continuous activation functions.

However, these techniques destroy crucial temporal aspects of SNNs---previous spikes of a neuron affect future spikes. In addition, the use of spikes in previous SNN models has required large temporal latency---a greater number of timesteps, in order to achieve more accurate performance on tasks. This makes scaling to deep network architectures with many layers computationally expensive. In this report, we review the proposed method of ``temporal spike sequence learning via backpropagation'' (known as TSSL-BP) which claims to deal with both of these problems by considering inter and intra-neuron spiking dependencies, and reducing the required number of timesteps.

Previous studies [19] [6] [15] [10] [7] [18] [16] [22] have demonstrated increasing accuracy of spike-based network algorithms on image classification datasets such as MNIST [9], Neuromorphic MNIST (N-MNIST) [12], Fashion-MNIST [20], and CIFAR-10 [8]. TSSL-BP demonstrates increased accuracy on all these datasets, including a 3.98% increase for the more challenging CIFAR-10. Critically, the network can not only perform at higher accuracy, but requires much shorter time-window.

The aim of the TSSL-BP algorithm is to learn a desired firing sequence, that can be set arbitrarily. The error function for the network to be minimised is the distance between the produced spiking pattern and the desired sequence (target). In TSSL-BP, the loss is defined as the sum of the squared error over all neurons for each timestep. The distance between the actual and desired spiking times is

L = \sum^{N_t}_{k=0} E[t_k]
= \frac{1}{2} \sum^{N_t}_{k=0}
\big(
(\epsilon * \textbf{d})[t_k] - (\epsilon * \textbf{s})[t_k]
\big)^2,

where E[t_k] is error at discrete timestep t_k, \textbf{d} and \textbf{s} are the desired and actual spike trains, and \epsilon is a kernel function measuring the Van Rossum distance between them [13]. The spike trains are binary sequences within a certain time-window.

Spikes in the neural network model are generated using the standard Leaky Integrate-and-Fire (LIF) model [4]. This model describes a neuron's membrane potential over time and generates a spike if the potential value is a higher than a specified threshold. Incoming spikes are converted into a postsynaptic current (PSC) a_j(t). The neuronal membrane potential u_i(t) for neuron i is

\tau_m \frac{du_i}{dt} = - u_i(t) + R \sum_j w_{ij}a_j(t) + \eta_i(t),

where R and \tau_m are leaky resistance and time constant of the membrane, w_{ij} is the synaptic weight between neurons i and j, and \eta_i is the reset function. The PSC and the reset function are defined as,

a_j(t) = (\epsilon * s_j)(t), \, \eta_i(t) = (\nu * s_i)(t),

where s_j is the spike times of neuron j, \nu is reset kernel and \epsilon is spike response. The spike response kernel is

\tau_s \frac{a_j}{dt} = - a_j(t) + s_j(t),

where \tau_s is synaptic time constant.

Finally, the firing output is determined by the Heaviside step function, H(.), producing all-or-none spiking depending on whether the membrane potential is over a specified threshold V_{th}:

s_i[t] = H(u_i[t] - V_{th}).

Spiking outputs are binary; all-or-none discrete events, meaning the activation function is not differentiable. Some SNN implementations [18] [16] [21] have circumvented this issue via use of surrogate gradient methods [11]. However, these methods degrade training performance due to discrepancies between the target loss and gradient. More recent SNN methods have reduced the number of timesteps required, however, still utilise continuous activation functions as approximations of the spiking neurons [19]. The approach of TSSL-BP considers the precise temporal dependencies of both spiking between neurons (inter) and within neurons (intra). Inter-neuron dependencies arise as the spikes from the presynaptic neurons cause changes in the postsynaptic neurons' current. Furthermore, due to the membrane potential reset kernel in the LIF model, the timing of spikes within a neuron can be dependent on previous spikes within a certain time-window. This affects the precise timing of spikes and the subsequent postsynaptic current. We refer the reader to see the original paper for the derivation.

In this reproduction, we test the following claims of the paper:

- TSSL-BP performs at a higher accuracy than previous spiking neural nets on supervised learning problems using the MNIST and CIFAR-10 datasets. A large increase of 3.98% on CIFAR-10 can be achieved, which is a challenging dataset for SNNs.
- Compared to previous SNNs, TSSL-BP utilizes a lower latency of spikes, whilst still maintaining high accuracy on the datasets.

To test these claims, we first checked the mathematical derivations provided in the paper, supplementary material and the source code implementation. Second, we tested the claims about performance accuracy by reproducing the results for the TSSL-BP method on the MNIST and CIFAR-10 datasets. An additional hyperparameter search was conducted for the MNIST dataset to assess whether the parameters selected in the original paper were justifiable.

The neural network architecture and the learning algorithm were implemented in PyTorch ML framework.^1 The network architecture is an adapted ConvNet, modified to allow spike generations. The network architecture used for MNIST dataset was 15C5-P2-40C5-P2-300, it has 210,375 trainable parameters in total. The CIFAR-10 dataset was tested on two different network architectures. The first one (CNN1) was 96C3-256C3-P2-384C3-P2-384C3-256C3-1024-1024 and the second (CNN2), larger network 128C3-256C3-P2-512C3-P2-1024C3-512C3-1024-512. For both, a fixed probability of 0.2 dropout was applied after each layer. The networks have 21,156,384 and 44,999,040 trainable parameters, respectively. Outputs of the model are converted to spike rates and tested against desired spike rates for each class. The target class is given a desired spike count, and other classes are set to target zero spikes.

At the beginning of network training, low initial weight values can lead to an absence of firing activity, meaning backpropagation with TSSL-BP is not possible. To solve this, the authors suggests to apply a warm-up mechanism, where an average firing rate threshold is set for each layer. When an activity is above this threshold, TSSL-BP is applied. If the firing activity is very low the warm-up is applied. In this case, the activation function is approximated using a continuous sigmoid function of membrane potential, allowing backpropagation without spiking.

MNIST is a prominent benchmarking dataset of handwritten digits for image recognition tasks. It includes 70,000 gray-scale input images of size of 28 \times 28 for 10 classes.Amongst these, 60,000 images are used for training and 10,000 for testing. CIFAR-10 is another well-known, image recognition benchmarking dataset. It includes 60,000 colour input images of size 32 \times 32 for 10 classes.
Amongst these, 50,000 images are used for training and 10,000 for testing. For both the MNIST and CIFAR-10 datasets, preprocessing was performed as in the original paper.^2 For each image, short time-windows of real-valued spike currents are generated from pixel intensities.

For the reproduction of the experiments, we used the same parameters as in the original paper and source code provided by authors. For both MNIST and CIFAR-10 datasets, batch size was 50, \tau_s (synaptic time constant) was 3, \tau_m (membrane time constant) was 5, time-window was 5 (with desired count of 4 and undesired 1). For MNIST, the networks were trained for 100 epochs at a learning-rate of 0.0005, and for CIFAR-10, 150 epochs at a learning-rate of 0.0002. An additional Bayesian hyperparameter search (12 runs) was performed for the MNIST dataset. The details of this experiment can be found in Results Beyond Original Paper section .

As in the original paper, we ran five trials each of the MNIST network and CNN1 network (CIFAR-10 dataset). Due to runtime limitations, CNN2 network was trained twice and the best performing is reported here. All performance data were measured by accuracy.

Our additional code is available online.^3 Weights and Biases API was implemented on the model code to track model learning and assist with analysis. Reproduction of the results for MNIST and CIFAR-10 datasets were run on a NVIDIA Tesla V100-PCIE-32GB GPU, and the hyperparameter search for MNIST dataset was run on a NVIDIA Titan RTX. The detailed GPU runtimes are:

- For the MNIST dataset, the mean run time was 1h 21m and the total GPU time for 5 runs was 6h 47m.
- For the CIFAR-10 dataset, the mean run time for CNN1 network was 18h 33m hours and the total GPU time for 5 runs was 92h 43m.
- For the CIFAR-10 dataset, the mean run time for CNN2 network was 25h 28m and the total GPU time for 2 runs was 50h 55m.
- For the MNIST dataset hyperparameter search, the total runtime of 12 runs was 56h 4m.

This section reports reproduction of two experiments from the paper; MNIST and CIFAR-10, and an additional hyperparameter search for MNIST. Overall, our results supports the claims in the original paper. Accuracy scores for each network reproduction were within reasonable margin of the original paper.

We conducted five runs for MNIST dataset, with the same hyperparameters as the original paper. Our reproduction produced a mean accuracy of 99.40% (see Table 1). Compared to the paper, this was within reasonable margin, original 99.50% with ours 0.1% lower. Between the best performance of each, the difference was only 0.06%.

Network | Mean Accuracy | Std. Deviation | Best Performance | |
---|---|---|---|---|

Original paper | `15C5-P2-40C5-P2-300` |
99.50% | 0.02% | 99.53% |

Reproduction | `15C5-P2-40C5-P2-300` |
99.40% | 0.04% | 99.47% |

Table 1: Performances comparison of the original paper and our reproduction for MNIST dataset.

For the MNIST dataset, we confirm that TSSL-BP outperforms most other SNNs [7] [10] [16] [18]. As in the original paper, it performs marginally below ST-RSBP network [22]. ST-RSBP achieves 99.57%, versus 99.40% for our replication and 99.50% reported in the original paper. However, ST-RSBP with the same network architecture requires 400 timesteps, versus only 5 for TSSL-BP. Given this, the performance for TSSL-BP is highly comparable to other SNNs. This result also provides support for the claim that TSSL-BP can perform well even with few time steps.

For CIFAR-10, the results of our replication can be found in Table 2. For the smaller CNN1 network, the original paper demonstrates best accuracy increases of 3.98% over STBP algorithm [19]. For our reproduction, we achieved mean accuracy of 88.96% versus 88.98% in the original paper. Best performance for the reproduction was slightly lower, 89.07% versus 89.22%. Compared to STBP, the best performance increase is 3.98% original and 3.83% reproduction.

Network | Mean Accuracy | Std. Deviation | Best Performance | |
---|---|---|---|---|

Original paper | `CNN1` |
88.98% | 0.27% | 89.22% |

Reproduction | `CNN1` |
88.96% | 0.10% | 89.07% |

Original paper | `CNN2` |
- | - | 91.41% |

Reproduction | `CNN2` |
- | - | 89.61 % |

Table 2: Performance comparison of the original paper and our reproduction for CIFAR-10.

In the original paper, it is unclear how many times the CNN2architecture was run. The accuracy reported in the original work is 91.41%, a 0.88% increase on STBP (with NeuNorm) [19]. In this reproduction, we ran the network twice and selected the highest accuracy of the two, 89.61% versus 89.53%. This is a lower performance than STBP, with a reduction of 0.92%. It is unclear whether TSSL-BP would consistently score lower over more trials, or whether the lower score obtained here was due to network stochasticity. Nevertheless, TSSL-BP utilises marginally fewer timesteps, with a reduction from eight for STBP (with NeuNorm) to five. The authors also report that there are no additional optimisations on TSSL-BP that are used in the comparable SNNs [19], such as neuron normalisation and population decoding.

We investigated the hyperparameters used in the MNIST network, the original parameters can be found in Table 3. As it is costly to run the network and impractical to search for large numbers of parameters, we performed a brief Bayesian hyperparameter search for learning-rate, number of epochs and time-window.

We utilised the sweep functionality from Weight & Biases ML developer tools.^4 For this search, we used Bayesian optimisation with the objective function improving the test-accuracy. We ran this optimisation 12 times, with parameters to be selected from:

- epochs \in \{50, 100, 150, 200\}
- learning-rate \in \{0.0001, 0.0005, 0.001, 0.005, 0.01\}
- time-window \in \{5, 10, 20\}

Parameter | Value | Parameter | Value |
---|---|---|---|

epochs | 100 | learning-rate | 0.0005 |

batch size | 50 | time-window | 5 |

desired count | 4 | undesired count | 1 |

$\tau_m$ | 5 | $\tau_s$ | 3 |

Table 3: Original hyperparameters used for MNIST.

Overall, the highest performance was 99.46%, using time-window of 20 for 200 epochs at learning-rate of 0.0005, however, this took 7h 22m. The lowest computational cost was 1h when using time-window of 5 for 100 epochs at learning-rate of 0.005 with a performance of 98.85%. Comparing this experiment with the paper, the original hyperparameters selected in the paper were well-optimised.

Overall, the reproduction study was fairly straightforward. The authors were helpful and provided clear explanations. Due to time constraints and limited resources available, we could only reproduce two out of the four experiments from the paper. However, our choice of the reproduced experiments was deliberate; we chose a well-known and relatively simpler dataset (MNIST) and another well-known but more complicated dataset (CIFAR-10). The reproduced accuracy results were within reasonable ranges to the authors' original paper results. For both MNIST and CIFAR-10 (using a smaller network structure) TSSL-BP outperforms most other SNN algorithms. Furthermore, we found that the reduced number of timesteps is sufficient to reproduce these accuracies, supporting claim two.

We performed an additional hyperparameter search to investigate the proposed learning algorithm's abilities outside of the selected parameter domain. This investigation revealed some interesting properties; such as that comparable performance can be achieved in a shorter runtime, and that the learning algorithm may have some instabilities. These insights can lead to further experimentation and perhaps further novel contributions in the future.

Authors provided the necessary source code for the learning algorithm and most network setups. This made the reproducibility study more fruitful. The only missing network setup was for CNN2, however, this can easily be reproduced by amending the layer sizes provided in the CNN1 file. We used W&B API for logging the results and plotting facilities, this made the collaboration experience easier and allowed us to monitor the network runs asynchronously.

Some parameters included in the original source code were undocumented. These are: a = 0.2 (line 89 in functions/tsslbp.py), th = 1/(4 * tau_s) (line 56 in functions/tsslbp.py), and theta = 1.1 (line 31-32 in layers/pooling.py). It was also unclear how the network weight clipping was determined (-8 and 8 for line 90 at tsslbp.py and -4 and 4 for weight_clipper function in layers/linear.py and layers/conv.py).^5 We contacted the authors to clarify these; a and th are used as rescaling factors and theta was not used in the code (i.e. redundant). Moreover, the authors confirmed that the particular values are empirically found and manually tuned. Finally, the network warm-up mechanism could be cumbersome for more complicated datasets.

We communicated with the author at the NeurIPS poster session, where our initial questions were answered surrounding the method, implementation and goals of the network. Following this we provided the authors with feedback on the details of some of the equations via email. We also enquired about the undocumented parameters given in the source code and the number of runs performed for the CIFAR10 dataset using CNN-2 network. We thank the authors for their engagement with this process.

We attempted to test the algorithm on another neuromorphic dataset used to benchmark SNN---a dynamic vision sensor (DVS) version of the CIFAR-10. During initial testing we found that large computational resources are required, and therefore did not proceed. We have provided the code for preprocessing of the dataset (based on [14]) in our code repository for future works to utilise.

The CNN2 network reproduction demonstrated lower accuracy than the STBP algorithm [18]. It is unclear whether this is due to variability of running a low number of trials or a more general trend. As fewer timesteps were used for the TSSL-BP implementation when comparing, it is possible TSSL-BP would achieve higher accuracy with the same number of timesteps. Future work could investigate whether comparing in this case yields higher accuracy as claimed by the authors.

- TSSL-BP implementation provided by the authors is available on Github.
- These datasets are downloadable as part of PyTorch: TorchVision.
- Our Github repo.
- Documentation for sweep function.
- These lines references are for the current state of the GitHub repository. The authors highlighted that the code is still under development for further optimisation, so these line references may change.

[1] Filipp Akopyan, Jun Sawada, Andrew Cassidy, Rodrigo Alvarez-Icaza, John Arthur, Paul Merolla, Nabil Imam, Yutaka Nakamura, Pallab Datta, Gi-Joon Nam, et al. Truenorth: Design and tool flow of a 65 MW 1 million neuron programmable neurosynaptic chip.IEEE Transactions on Computer-aided Design of Integrated Circuits and Systems, 34(10):1537–1557, 2015.

[2] Lukas Biewald. Experiment tracking with weights and biases, 2020. Software is available from wandb.com.

[3] Mike Davies, Narayan Srinivasa, Tsung-Han Lin, Gautham Chinya, Yongqiang Cao, Sri Harsha Choday, Georgios Dimou, Prasad Joshi, Nabil Imam, Shweta Jain, et al. Loihi: A neuromorphic manycore processor with on-chip learning.IEEE Micro, 38(1):82–99, 2018.

[4] Wulfram Gerstner and Werner M Kistler.Spiking neuron models: Single neurons, populations, plasticity. Cambridge University Press, 2002.

[5] Samanwoy Ghosh-Dastidar and Hojjat Adeli. Spiking neural networks. International Journal of Neural Systems,19(04):295–308, 2009.

[6] Eric Hunsberger and Chris Eliasmith. Training spiking deep networks for neuromorphic hardware. arXiv preprint arXiv:1611.05141, 2016.

[7] Yingyezhe Jin, Wenrui Zhang, and Peng Li. Hybrid macro/micro level backpropagation for training deep spiking neural networks.arXiv preprint arXiv:1805.07866, 2018.

[8] Alex Krizhevsky, Vinod Nair, and Geoffrey Hinton. The CIFAR-10 dataset.online: http://www.cs.toronto.edu/kriz/cifar. html, 55, 2014.

[9] Yann LeCun, Léon Bottou, Yoshua Bengio, and Patrick Haffner. Gradient-based learning applied to document recognition. Proceedings of the IEEE, 86(11):2278–2324, 1998.

[10] Jun Haeng Lee, Tobi Delbruck, and Michael Pfeiffer. Training deep spiking neural networks using backpropagation. Frontiers in Neuroscience, 10:508, 2016.

[11] Emre O Neftci, Hesham Mostafa, and Friedemann Zenke. Surrogate gradient learning in spiking neural networks: Bringing the power of gradient-based optimization to spiking neural networks. IEEE Signal Processing Magazine,36(6):51–63, 2019.

[12] Garrick Orchard, Ajinkya Jayawant, Gregory K Cohen, and Nitish Thakor. Converting static image datasets to spiking neuromorphic datasets using saccades. Frontiers in Neuroscience, 9:437, 2015.

[13] MCW van Rossum. A novel spike distance. Neural Computation, 13(4):751–763, 2001.

[14] Ali Samadzadeh, Fatemeh Sadat Tabatabaei Far, Ali Javadi, Ahmad Nickabadi, and Morteza Haghir Chehreghani. Convolutional spiking neural networks for spatio-temporal feature extraction, 2020.

[15] Abhronil Sengupta, Yuting Ye, Robert Wang, Chiao Liu, and Kaushik Roy. Going deeper in spiking neural networks: Vgg and residual architectures.Frontiers in Neuroscience, 13:95, 2019.

[16] Sumit Bam Shrestha and Garrick Orchard. Slayer: Spike layer error reassignment in time.arXiv preprint arXiv:1810.08646, 2018.

[17] Amirhossein Tavanaei, Masoud Ghodrati, Saeed Reza Kheradpisheh, Timothée Masquelier, and Anthony Maida. Deep learning in spiking neural networks.Neural Networks, 111:47–63, 2019.

[18] Yujie Wu, Lei Deng, Guoqi Li, Jun Zhu, and Luping Shi. Spatio-temporal backpropagation for training high-performance spiking neural networks. Frontiers in Neuroscience, 12:331, 2018.

[19] Yujie Wu, Lei Deng, Guoqi Li, Jun Zhu, Yuan Xie, and Luping Shi. Direct training for spiking neural networks: Faster, larger, better. InProceedings of the AAAI Conference on Artificial Intelligence, volume 33, pages1311–1318, 2019.

[20] Han Xiao, Kashif Rasul, and Roland Vollgraf. Fashion-MNIST: a novel image dataset for benchmarking machine learning algorithms. arXiv preprint arXiv:1708.07747, 2017.

[21] Friedemann Zenke and Surya Ganguli. Superspike: Supervised learning in multilayer spiking neural networks. Neural computation, 30(6):1514–1541, 2018

[22] Wenrui Zhang and Peng Li. Spike-train level backpropagation for training deep recurrent spiking neural networks. arXiv preprint arXiv:1908.06378, 2019.

[23]Wenrui Zhang and Peng Li. Temporal spike sequence learning via backpropagation for deep spiking neural networks. In Advances in Neural Information Processing Systems, 2020.
